ROYAL 111 SMOOTH-1.28Plumbing · Submittal package
The submittal engineers approve on first review.
A spec-response package for Keystone Plumbing Agency, a fictional plumbing and water agency, answering a commercial plumbing fixtures section. It has a branded cover sheet, a line-by-line compliance matrix and an indexed cut-sheet set, so the engineer never has to hunt for anything.
Submittal 22 42 00-01 · 3 of 18 pages shown
Keystone Plumbing AgencyTransmittal
Product submittal
Section 22 42 00
Commercial Plumbing Fixtures
Prepared for engineer's review and approval
- Project
- Riverside Community Health Centre, Phase 2
- Engineer
- Halden Morrow Engineering
- Contractor
- Brightwater Mechanical Ltd.
- Submittal no.
- 22 42 00-01, Rev 0
- Date
- November 12
- Prepared by
- Keystone inside sales & applications
FOR REVIEW
Rev 0
Rev 0
Keystone Plumbing Agency1 / 18
Compliance matrix22 42 00
| Spec ref. | Requirement | Proposed product | |
|---|---|---|---|
| 2.1.A | Water closet flush valve, sensor operated, 1.28 gpf | Sloan ROYAL 111 SMOOTH-1.28 | ✓ |
| 2.2.A | Lavatory faucet, sensor, 0.5 gpm max | Moen Commercial M-POWER CA8304 | ✓ |
| 2.3.A | Filtered bottle-filling station, touchless | Elkay ezH2O LZS8WSLK | ✓ |
| 2.4.A | Floor drain, cast iron body, adjustable strainer | Zurn Z415-BZ1 | ✓ |
| 2.5.A | Reduced pressure zone backflow assembly, lead free | Watts LF909 | ✓ |
| 2.6.A | Finish: polished chrome | Per manufacturer standard | Note |
Note 2.6.A: confirm finish on lavatory faucet trim with engineer; alternate finish available.
Rev 02 / 18
Cut-sheet indexAppendix A
- A1Sloan ROYAL 111 SMOOTH-1.283
- A2Moen Commercial CA83046
- A3Elkay LZS8WSLK8
- A4Zurn Z415-BZ111
- A5Watts LF90913
- B1Warranty & certifications summary16
- B2Installation & maintenance links17
- C1Contact & lead-time sheet18
Cut sheets are reproduced from each manufacturer's current published documents, with the model numbers for this project highlighted.
Rev 03 / 18
Select a page to open it in page view
Products on this submittal
Real models, published specs, linked sources.
ROYAL 111 SMOOTH-1.28
CA8304
LZS8WSLKElkay
ezH2O filtered bottle filling station
- 8.0 GPH chilled
- 1.1 GPM fill
- Touchless sensor
Z415-BZ1
LF909Specs from each manufacturer's published product page; photos are representative (credits). Brand names belong to their owners.
Specified on paper, judged in the finished space.Photo: Wikimedia Commons · credits
